Vandersteen -VCC-5 - 3-Way Center Speaker


Model #:

VCC-5

Model #: VCC-5
1732070
Vandersteen
$3,300.00

At a Glance

Combining Science, Music, and Home Theater, the VCC- 5 Reference Center speaker sets new standards. The VCC-5 Reference Center was developed to ideally match with Vandersteen's Quatro Wood CT, Model 5A Carbon, KĒNTO Carbon, and Model Seven speakers in high-performance multi-channel systems.Read More

Price Starting At
$3,300.00

Additional Finishes AvailableCall for Best Pricing!

Get to know this product.

Product Overview

Product Overview

Vandersteen's Reference Center!

The VCC- 5 is a three-way design based on the VCC- 1, but with the addition of two (2) 6.5-inch cast-basket woofers. These woofers are internally mounted and cross over at 150Hz to the coaxial system, which has a crossover frequency of 3500Hz. A true “triaxial” output is achieved by channeling bass around the midrange-tweeter coaxial array. This eliminates the severe comb filter lobing produced by horizontally displaced drivers. The result is reference-level performance, both in measurement and sound, regardless of off-axis perspective above, below or to the right or left of the speaker. While not an easy design goal to meet, we feel this property is mandatory for a proper center speaker and it is found in all of our VCC’s. The VCC- 5 Reference preserves the coherence of the VCC-1 Signature and VCC-2 while broadening frequency extension, lowering distortion and increasing power handling.

VCC-5 Specifications

Coaxial Midrange/Tweeter - 6.5” Mineral-Filled Polycone with Die-Cast Basket with 1” Critically-Damped Alloy-Dome Tweeter

Woofer(s) - (2) 6.5” Mineral-Filled Polycone with Die-Cast Basket

Recommended Amplification - 100-200 Watts Into 8 Ohms

Frequency Response - 50Hz – 30kHz +/- 2dB

Sensitivity - 85 dB, 1 meter with 2.83 volt input

Impedance - 6 ohms nominal 4 ohms minimum

Crossovers - First order/6dB per octave, 150Hz, 3.5kHz

Input Terminals - Barrier strips, 7/16" max width

Dimensions (WHD) - 24” x 9 3/4” x 18”

Weight - 68 lbs. Net

Country of Manufacture - Made in the USA

Useful Documents
Specifications

General Specs

Made InUSA
Made In The USAYes
Speaker Depth (in.)18
Speaker Width (in.)24
Speaker Height (in.)9.75
Speaker Weight (lbs)68
Frequency Response50Hz – 30kHz +/- 2dB
Impedance6 ohms nominal 4 ohms minimum
Sensitivity85
