Product Overview
DSP MKIII amplifiers feature SonARC (Sonance Advanced Room Correction), which offers hundreds of EQ presets designed specifically for Sonance and James speakers available through simple pull-down menus. SonARC enable effortless DSP without additional hardware, software, and more importantly, time. For additional customization, SonARC provides a 10-band parametric EQ to optimize sonic performance in any space.
DSP MKIII amplifiers are engineered to be smaller yet more powerful than legacy Sonance models. The resulting power density allows for 130W or 150W in a mere 1U rack space while maintaining an industry-leading 93% energy efficiency.
At the core of every DSP amplifier is a powerful 24 bit/96K DAC, capable of handling a full 4608 Kbps of audio data. Most amplifiers have processing limitations that constrain the audio output and limit the maximum amount of pass-through information to 1411 Kbps which compromises the quality of the listening experience. Sonance DSP amplifiers enable listeners to enjoy the full clarity and output of whatever audio passes through, from MP3 to full High-Resolution Audio.
High resolution 24 bit/96 kHz processing DAC capable of 4608 KBPS audio playback.
IP and IR controllable via for the ultimate in installation flexibility
Powerful, audiophile grade Class-D amplification, rated and certified at 8 and 4 ohms and stable to 2 ohms.
145 watts RMS per Channel @ 4 ohms; 130 watts RMS per Channel @ 8 ohms
Compact form factor allows for space savings in the equipment rack with ample power to the speakers.
Class-D design is 93% efficient for maximum power output with minimal power usage. Meets EU power saving standards.
Terminal blocks will accept up to 12AWG speaker cable for longer runs and higher performance.
Full array of input/output connectivity for maximum installation flexibility: Line input/loop outputs; IP, IR, audio and voltage triggers; Ethernet jack for network connectivity
Bridgeable channels for applications when even more power is required.
Certified to worldwide safety standards. (TUV to UL standards, CE, RCM, C-Tick, RoHS, WEEE). Meets FCC standards.
Rack ears and removable feet included.
Digital Input Module compatible.
