JBL Synthesis® SCL-4 7" White In-Wall/In-Ceiling Loudspeaker
At a Glance
JBL Synthesis® SCL-4 In-Wall/In-Ceiling Loudspeaker with magnetic grille and high-performance passive network
Proposition 65 Warning for California Residents
Connections
| Connector Type | Dual Gold-Plated Five-Way Binding Posts |
|---|
Construction
| Driver Component Size | 1" |
|---|
Dimensions
| Mount Depth | 3.84 |
|---|
Other
| Crossover Type | 1.3 kHz |
|---|
General Specs
| Product Weight (lbs.) | 27.6 |
|---|---|
| MPN | SCL-4 |
| Frequency Response | 45Hz – 33kHz |
| Color Finish Name | White |
| Color | White |
| Impedance | 6 ohms |
| Sensitivity | 91 |
| Depth (in.) | 4 |
| Height (in.) | 25.35 |
| Width (in.) | 16.45 |
| Woofer Size | 7" |
CALL US!
JBL Synthesis® SCL-4 7" White In-Wall/In-Ceiling Loudspeaker
Model #: SCL-4
Request a Quote
Call for Availability
512-454-4534
At a Glance
Get to know this product.
The JBL brand has become synonymous with the cinema experience. The SCL-4 continues this legacy. The two-way SCL in-wall loudspeakers are the first flush-mount compression driver loudspeakers using JBL Professional technology. The 7" cast-frame aluminum-cone woofer is ideal for in-wall or ceiling mounts. Utilizing the D2-derived 1-inch / 25mm annular ring Teonex® diaphragm compression driver with advanced HDI geometry horn, the SCL-4 provides extraordinary performance in a very small package.
7” (180mm) cast-frame, advanced aluminum matrix cone woofer with large ferrite low-distortion motor structure
D2-derived 1" (25mm) 2409H annular ring diaphragm Teonex® compression driver
Patented High-Definition Imaging (HDI™) technology provides elevated performance in combination with patented D2-Series compression driver.
Design can be installed in any orientation, for maximum installation flexibility
Ideal for LCR or surround channel use
Patent Pending extended range L-Bracket mounting system
Low resonance, well-damped MDF wood rear enclosure
High-performance passive network utilizing all air-core inductors, polypropylene capacitors
Zero-bezel, magnetically-attached grille
Dual binding post inputs for bi-wire or bi-amplified connections
