JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker


Model #:

SCL-3

Model #: SCL-3
174216
JBL Synthesis
$99,999.00

At a Glance

Product Dimensions 16.46"h x 16.46"w x 6.01"d

JBL Synthesis® SCL-3 In-Wall/In-Ceiling Loudspeaker with magnetically-attached grille and unique center mounting pointRead More

Request a Quote

Call for "Open Box" & "Demo" Deals - 512-454-4534

Get to know this product.

Product Overview

Product Overview

The JBL brand has become synonymous with the cinema experience. The SCL-3 was designed to continue this legacy. The two-way SCL in-wall loudspeakers are the first flush-mount compression driver loudspeakers using JBL Professional technology. The dual 5-¼" cast frame aluminum woofers are ideal for in-wall or ceiling mounting. Utilizing the D2-derived 1-inch / 25mm annular ring compression driver with Teonex® diaphragm and an advanced HDI geometry horn, the SCL-3 provides unparalleled performance compared to any in-wall loudspeaker in the market today.

  • Dual 5-¼"” (130mm) cast-frame, advanced aluminum matrix cone woofers with low-distortion neodymium motor structures
  • D2-derived 1" (25mm) 2409H annular ring, Teonex ® diaphragm, compression driver
  • Patented HDI™ (High-Definition Imaging) technology provides elevated performance in combination with patented D2-Series compression driver.
  • Design can be oriented in any of the four possible directions for flexibility in applications as an in-wall surround, in-wall LCR, or in-ceiling overhead height channel
  • Ideal for overhead channel flush-mount for Dolby Atmos or similar Immersive surround sound installations
  • Patent Pending extended range L-Bracket mounting system
  • Zero-bezel, magnetically-attached grille
  • Dual binding post inputs for bi-wire or bi-amplified connections
  • Low resonance, well damped MDF wood rear enclosures
  • Unique center mounting point to aid installation and greatly minimize baffle resonances
  • High-performance passive network utilizing all air core inductors, polypropylene capacitors
Useful Documents
Specifications

General Specs

Product Weight (lbs.)24.3
MPNSCL-3
Color Finish NameWhite
Frequency Response65Hz – 33kHz
ColorWhite
Impedance6 ohms
Sensitivity91
Depth (in.)6.01
Height (in.)16.46
Width (in.)16.46
Woofer Size5.25" x 2

Connections

Connector Type:Dual Gold-Plated Five-Way Binding Posts

Construction

Driver Component Size:1"

Other

Crossover Type:1.3 kHz
