JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker

CALL US!

JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 0
JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 1
JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 2
JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 3
JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 4
JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker 5

JBL Synthesis® SCL-3 5.25" White In-Wall/In-Ceiling Loudspeaker

Model #: SCL-3
174216
JBL Synthesis
At a Glance
JBL Synthesis® SCL-3 In-Wall/In-Ceiling Loudspeaker with magnetically-attached grille and unique center mounting point
Request a Quote

Call for Availability

512-454-4534


Get to know this product.

The JBL brand has become synonymous with the cinema experience. The SCL-3 was designed to continue this legacy. The two-way SCL in-wall loudspeakers are the first flush-mount compression driver loudspeakers using JBL Professional technology. The dual 5-¼" cast frame aluminum woofers are ideal for in-wall or ceiling mounting. Utilizing the D2-derived 1-inch / 25mm annular ring compression driver with Teonex® diaphragm and an advanced HDI geometry horn, the SCL-3 provides unparalleled performance compared to any in-wall loudspeaker in the market today.

  • Dual 5-¼"” (130mm) cast-frame, advanced aluminum matrix cone woofers with low-distortion neodymium motor structures
  • D2-derived 1" (25mm) 2409H annular ring, Teonex ® diaphragm, compression driver
  • Patented HDI™ (High-Definition Imaging) technology provides elevated performance in combination with patented D2-Series compression driver.
  • Design can be oriented in any of the four possible directions for flexibility in applications as an in-wall surround, in-wall LCR, or in-ceiling overhead height channel
  • Ideal for overhead channel flush-mount for Dolby Atmos or similar Immersive surround sound installations
  • Patent Pending extended range L-Bracket mounting system
  • Zero-bezel, magnetically-attached grille
  • Dual binding post inputs for bi-wire or bi-amplified connections
  • Low resonance, well damped MDF wood rear enclosures
  • Unique center mounting point to aid installation and greatly minimize baffle resonances
  • High-performance passive network utilizing all air core inductors, polypropylene capacitors
Specifications

Connections

Connector Type:Dual Gold-Plated Five-Way Binding Posts

Construction

Driver Component Size:1"

Other

Crossover Type:1.3 kHz

Misc. Specs

Product Weight (lbs.)24.3
MPNSCL-3
Frequency Response65Hz – 33kHz
Color Finish NameWhite
ColorWhite
Impedance6 ohms
Sensitivity91
Depth (in.)6.01
Height (in.)16.46
Width (in.)16.46
Woofer Size5.25" x 2
